FLUSH PULLS

TYDIX Flush Pulls are ground and polished to furnish a square, flat dress face unusually free of blemishes. All outside edges and corners are clean and sharp in appearance. Important inside surfaces are smoothed to a practical degree. All inside corners of the dress face are filed to full, sharp, square corners

TYDIX Flush Pulls are available in a considerable variety of finishes and finish combinations. That is, the hardware finish of the dress face may be contrasted with, or complemented by, the color treatment inside the frame and/or color or finish of the back plate.

Accordingly, there are three "areas" where your color plans might be carried out: the Dress Face, inside the frame, and the Back Plate. The following lists finishes or colors which might apply to each of these areas:

DRESS FACE FINISH
SYMBOL
Polished BrassUS 3
Satin BrassUS 4
Polished BronzeUS 9
Satin BronzeUS 10
Oil-Rubbed BronzeUS10B
Polished NickelUS 14
Satin NickelUS 15
Polished ChromeUS 26
Satin ChromeUS 26D
Statuary BronzeSpecify
Antique BronzeSpecify
Satin BlackSpecify
INSIDE FRAME COLOR
SYMBOL
Satin BlackBlk.
Brass Spray236
Bronze Spray277
Dark Bronze Spray275
Chrome Spray266
BACK PLATES
METALCOUNTERTOP LAMINATESSYMBOL
Same as Dress FaceSatin BlackBlk.
(Satin finishes recommended)Other Color or Texture (Customer to supply)Specify
When ordering specify per following examples:
FLUSH PULL NODRESS FACEINSIDE FRAMEBACK PLATEOTHER
61064US10BXBlk.XBlk.TMP (tamperproff screws)
61063US10BX275XUS10B
61064US10X277XBlk.
flush-image-1
No. 610644" X 2-1/2"
flush-image-2
No. 610632" X 2-1/2

Specify:

Flush pull number

Hardware finish of Face

Color inside Frame

Back Plate color

(Example: No. 61064, US 10B X Blk.)

Specify:

TMP for tamperproof screws

Two PullsOne Door
flush-image-3
Single Pullfor Doors andDrawers
flush-image-4
No. 72075TBI 4" X 2-1/2"
flush-image-5
No. 72075BB2 4" X 2-1/2"
flush-image-6
edge

Single Pulls for Hollow Metal

72075 - TBI
edge

Back-to-Back Pulls for Hollow Core Doors

72075 - BB2 72075 - TBI

No. 621346" X 3-3/8"
edge
edge

No. 62134 6" X 3-3/8"

edge

Single Pulls for Doors and Drawers 62134

Specify:

Flush pull number

Hardware finish of Face

Color inside Frame

Back Plate color

(Example: 62134 US 10B X Blk.)

Specify:

TMP for tamperproof screws (Full flush installation of pulls is not recommended.)


No. 20454-1/2"x 2-3/8"
edge

For Drawers

edge
edge

Top View 2045

No. LK1-20454-1/2"x 2-3/8"
edge

Locking Pulls for Drawers

edge
edge

NOTE: Flush Pull No. LK1-2045 Dress face is available in chrome or nickel finishes only
